arterial blood gas analyzer blood gas system blood gas | |||
Technical Data | |||
sample | whole blood 150μl | ||
Test Method | automatic sampling | ||
Testing time | 50s | ||
printer | build-in thermal printer | ||
display screen | 8" TFT colorful LCD touch | ||
screen | |||
storage volume | >=5000 | ||
Interfaces | RS232 ,Barcode scanner | ||
temperature | +15ºC -- +30ºC | ||
Relative humidity | <=85% | ||
Power supply | 110V~240V ,50HZ | ||
Model | analysis project | parameters | |
PH(TC),PCO2(TC),P02(TC),HCO3- | |||
MCL-2000 | PH,PCO2,PO2,Na+,K+,Cl-,Ca2+ | ,SBC,BE,Beecf,TCO2,SO2%,P50,A- | |
Ado2,RI,Tca,nCa | |||
PH(TC),PCO2(TC),P02(TC),HCO3- | |||
MCL-L2200 | PH,PCO2,PO2 | ,SBC,BE,Beecf,TCO2,SO2%,P50,A- | |
Ado2,RI | |||
Measurement range
blood gas | pH value | 6.800~8.000 | PH | |
carbon dioxide pressure | 8.0~200.0mmHg | PCO2 | ||
analyser | ||||
oxygen partial pressure | 0~800.0mmHg | PO2 | ||
Na+ | 50~200mmol/L | Na+ | ||
ionometric | K+ | 1.5~10mmol/L | K+ | |
method | Cl- | 50~200mmol/L | Cl- | |
Ca2+ | 0.5~5.0mmol/L | Ca2+ | ||
Hydrogen carbonate root | 22.0~26.0mmol/L | HCO3- | ||
standard bicarbonate | 22.0~26.0mmol/L | SBC | ||
Whole blood alkali super | -2.0~2.0mmol/L | BE | ||
Extracellular fluid | -2.0~2.0mmol/L | Beecf | ||
Of All Co2 Emissions | 23.0~27.0mmol/L | TCO2 | ||
parameter | oxyhemoglobin saturation | 93..0~99.0% | SO2% | |
Half a saturation oxygen | 25.5~28.5mmHg | P50 | ||
The alveolar arterial | 5~50mmHg | A-aDO2 | ||
RSBI | <0.15 | RI | ||
STCa | 0.5~10.0mmol/L | Tca | ||
Standard calcium | 0.3~5.0mmol/L | nCa |
